Product features
1. Photographing, typesetting and positioning, and automatic measurement of plate thickness and tool size.
2. Use good computer system control, simple operation, high efficiency.
3. Choose good quality electrical appliances with long service life and low maintenance cost
4. The native supports one-click transformation in multiple languages.
Product parameters and price
Programming method
Manual programming
Programming method 2
CAD The import
Control method
CNC
Main motor power
7.5kw
Working voltage
380V-3phase/50HZ
Speed R.P.M
1000-6000r/min
Blade size
350-400mm
X-axis working stroke
3500mm
Y-axis working stroke
2000mm
A-axis working stroke
360°Rotate freely
B-axis working stroke
0-90°Automatic chamfering
Cutting thickness
80mm
Processing precision
0.2mm
Working table size
3500*2000mm
Tilting working table
YES
Camera
YES
Overall size
5800*3120*3320mm
Weight
3900KG
|
